# LS2 Universal Manipulator

With a weight capacity up to 113 kgs. / 250 lbs.

The LS2 Manipulator supports high power test solutions. With motorized vertical motion, quickly move from probe to service/engineering positions.

The LS2 Manipulator integrates easily to inTEST 4CAM, INTELLIDOCK and prober compression ring for accurate and reliable docking.

### Key Features

![](https://www.intest-ems.com/hubfs/raw_assets/public/miles-theme/images/checkmark.png)

 Cable load management to protect delicate tester cables







![](https://www.intest-ems.com/hubfs/raw_assets/public/miles-theme/images/slider-arrow-prev.png)

![](https://www.intest-ems.com/hubfs/raw_assets/public/miles-theme/images/slider-arrow-next.png)

## Compatible Testers

The LS2 Manipulator supports the High Power Test Solutions for the ETS-88 DP-32.

![](https://www.intest-ems.com/hubfs/raw_assets/public/miles-theme/images/checkmark.png)

**Teradyne**

 <>

[Find your specific application ](https://www.intest-ems.com/applications?hsLang=en)

![LS2](https://www.intest-ems.com/hubfs/LS2.png)



## Quickly and easily setup ATE to wafer probe

Features powered vertical motion and 6 axis of complaint motions for ease of docking and undocking.

[Download Brochure](https://www.intest-ems.com/manipulators/ls2#modal-brochure)

## Technical Specifications

For high power test solutions

[

 Collapse Specs

](https://www.intest-ems.com/manipulators/ls2#)

**Example specifications—actual specifications are application specific.**

| Maximum Load Rating | 113 kg (250 lbs) |
| --- | --- |
| Vertical Travel | 973 mm (38.3") |
| Vertical compliance | +/- 12 mm (0.5") |
| Swing | 190° |
| Twist | 190° |
| Tumble | 5° |
| Theta | 5° |
